Ubiquiti ES-18X EdgeSwitch 18X

Mechanical.

Dimensions:

299.8 x 160 x 43.7 mm (11.8 x 6.3 x 1.7")

Weight:

Without Mount: 1.15 kg (2.54 lb)

With Mount: 1.43 kg (3.15 lb)

Enclosure Material:

Metal

Mount Material:

Metal

Hardware.

Total Non-Blocking Throughput:

18 Gbps

Switching Capacity:

36 Gbps

Forwarding Rate:

26.78 Mpps

Max. Power Consumption:

14W (Excludes PoE Output)

ESD/EMP Protection:

Air: ± 16 kV, Contact: ± 8 kV

Power Method:

External AC/DC Adapter

24V Passive PoE

Power Supply:

24VDC, 1.0A Power Adapter (Included)

24V Passive PoE

Supported Voltage Range:

9 - 30VDC

Networking Interfaces:

(16) 10/100/1000 Mbps Ethernet RJ45 Ports

(2) 1 Gbps SFP Ports
