Ubiquiti USW-WAN-RJ45 Switch / Gateway (1) 1 GbE RJ-45 (3) 10G SFP+

10 GbE WAN Switch linking two Shadow Mode High Availability UniFi Gateways to a single ISP.

Specifications:

Dimensions: 442.4 x 120 x 43.7 mm (17.4 x 4.72 x 1.7")

Port Layout

• 1 GbE RJ45: 1 (1G/100M/10M)

• 10G SFP+: 3 (10G/1G)

• Redundancy: (2) AC inputs

• Form Factor: Rack mount (1U)

Performance

• Switching Capacity: 20 Gbps

• Total Non-Blocking Throughput: 10 Gbps

• Forwarding Rate: 15 Mpps

Hardware

• Max. Power Consumption: 18W

• Power Method: (2) Universal input, 100—240V AC, 50/60 Hz

• Power Input Method: AC input

• Power Supply: (2) AC/DC, internal, 36W

• Supported Voltage Range: 100—240V AC

• Management: Ethernet

• Weight: Without mounting brackets: 2.3 kg (5.1 lb)

• With mounting brackets: 2.4 kg (5.3 lb)

• Enclosure Material: SGCC steel

• Mount Material: SGCC steel

• ESD Protection: Air: ± 16kV, contact: ± 10kV

• Ambient Operating Temperature: -5 to 40° C (23 to 104° F)

• Ambient Operating Humidity: 10 to 90% noncondensing

LEDs

• Ethernet ✓

• System ✓

Certifications

• CE, FCC, IC

• NDAA Compliant  ✓
