WyreStorm EX-100-H2 Extender HDBaseT 100m 4K with USB

The EX-100-H2 uses the powerful HDBaseT 2.0 chipset to send along 4K, USB, PoH and HD audio up to 100m/328ft with a single Cat 6 cable. This extender hosts the perfect combination of features to give you the tools you need to set up your next conference or presentation. With separate audio lanes, you’re free to send audio independently to overlay your presentation.

With data transfers in mind, the EX-100-H2 is equipped with the fastest USB hardware HDBaseT is currently capable of; USB 2.0 and up to 190Mbps, which is everything you need to set up HD webcams, smart whiteboards, transfer data and so much more!

HDBASET SPEC 2.0

Featuring the powerful Class C HDBaseT chipset, UHD video & audio, USB, RS-232 and PoH are sent and distributed losslessly over distances of 100m/328ft.

USB 2.0 PASSTHROUGH

Equipped with the HDMI USB extender 2.0 spec, the EX-100-H2 not only provides KVM functionality for extension of keyboard/mouse or touchscreen, but also transfers the highest data rate that HDBaseT has to offer of 190Mbps, for webcams, white boards and USB data drives.

BIDIRECTIONAL AUDIO LANE

Two separate audio feeds can also be sent bidirectionally, thanks to a dedicated audio pass-through that allows 2ch analog to be sent and received at either end completely independent of the HDMI signal.

Supports the latest UHD resolutions including HDR10, HDR 10+, HLG and Dolby Vision formats

Extend 4K@60Hz (4:2:0) content up to 100/328ft meters using Cat6a cabling or higher

USB data transfers of up to 190Mbps for webcams and peripherals

High-speed USB 2.0 pass-through up to 100 meters/328ft

Supports full CEC passthrough via TV remote to control connected AV equipment such as AVR volume or menu navigation

PoH allows the transmitter to power the receiver over category cable

Backwards compatible with HDBaseT 1.0 transmission and receiving devices (lowest denominator takes priority)

LED indication for power supply to units, signal status to show established display connection, HDCP presence in signal and transmission link

Locking DC power jacks

12v DC PSU with US, UK, EU & AU Power cables included

Mounting brackets included

Specifications:

Inputs

• TRANSMITTER

1x HDMI: 19-pin type A

1 x Audio: 3.5mm (1/8in)

TRS Stereo

• RECEIVER

1 x HDBT: 8-pin RJ45 Female

1 x Audio: 3.5mm (1/8in) TRS Stereo

Outputs

1x HDBT: 8-pin RJ-45 Female

1x Audio: 3.5mm (1/8in)

TRS Stereo

1x HDMI: 19-pin type A

1x Audio: 3.5mm (1/8in) TRS Stereo

• Output Video Encoding: HDBaseT Class C

• Encoding Data Rate: 10.2Gbps

• End to End Latency: 10μs (microseconds)

• Audio Formats: 2ch Analog/PCM | Multichannel: LPCM up to DTS-X and Dolby Atmos

• Video Resolutions (max)

• 1920x1080p @60Hz 12bit

• 3840x2160p @30Hz 8bit 4:4:4

• 3840x2160p @30Hz 12bit 4:2:2 HDR

• 3840x2160p @30Hz 8bit 4:4:4 HDR

• Supported Standards: DCI | RGB | HDR10 | Dolby Vision up to 30Hz | HLG | BT.2020 | BT.2100

• Maximum Pixel Clock: 340MHz

• HDMI: HDMI | HDCP 2.2 | EDID | CEC Pass-through | DVI/D supported with adapter (not included)

• HDBaseT: HDMI | HDCP 2.2 | EDID | Line Audio | 1-way PoH (TX powers RX) | Bidirectional RS-232 | CEEC

• RS-232: 1x RS-232: 3-pin Phoenix (Transmitter and Receiver)

• USB: 1x Type B (host | 4x Type A (device)

• Maximum uplink speed: 190Mbps

• Power Supply: 12V DC 2A

• Max Power Consumption: 12W
